MIL-S-1123E
TABLE II - Type I, size B shoe finishing machine (cont'd)
Quantity
Item No.
Nomenclature
Required
Brush, burnishing.
10
1
11.
Brush shank, 1-1/2 inch width by 8 inch
diameter.
1
12
Iron, edge, sole and heel.
1
3.10.2 Type II, sole stitching machine.- The sole stitching machine
shall be a heavy-duty, self-contained, curved-needle type, electric motor
driven machine designed for stitching outer soles to shoes with a type
301 stitch conforming to Fed. Std. No. 751. An electrically heated wax
pot equipped with thermostatic heat control shall be incorporated in the
machine. The stitching machine shall be connected to the motor by a belt
and shall contain a clutch designed to allow the stopping of its operation
at any time while the motor is running. The machine shall be set so its
speed does not exceed 350 revolutions per minute (r.p.m.) One set of
special tools and wrenches required for operation and adjustment shall be
furnished with each machine.
3.10.3 Type IV, shoe soling press.- The shoe soling press shall be a
laminating, floor mounted, rotary, 5 pair capacity machine with electrically
heated pads (see 6.3). Pressure shall be applied by a handwheel controlling
cross arm and pressure screws.
3.10.3.1 Accessories.- The following equipment shall be included with
the sole press:
10 pair men's lasts - sizes 6-7-8-9-11DP, 7-8-9-10-12Ds
1 pair men's adJusters
12 pair women's lasts - sizes 3-5-7-10C, 4-6GG,
3-4-5-6-8-9MC
6 pair toe plates for women's lasts - sizes 4-6-8C, 8GG, 7-10
2 pair toe plate thumb screws
1 cement pot and brush
1 wire brush
5 feet rubber welter
1 hand wire rougher
1 welt brush
3.10.4 Type V, sewing machine, industrial shoe batching.- The patching
machine shall be a cylinder bed, single needle machine conforming to type IV,
style A, class 5 of OO-S-256. The machine shall produce a lock stitch type
8
