MIL-S-1123E
TABLE I - Type I, Size A shoe finishing machine (cont'd)
Quantity
Item No.
Nomencalture
Required
Grinder attachment.
1
4
Heel breaster.
1
Scouring Wheel, flat surface 1-3/8 inch
5
width by 5 inch diameter (with metal
Protective edge when specified (see 6.2) ).
1
6
Bottom sander 4-1/2 inch width.
1
Scouring wheel, flat surface, 1-3/8 inch
7
width by 5 inch diameter (with metal
protective edge when specified (see 6.2) ).
1
8
Brush, shank, 1-1/2 inch width by 8 inch
diameter.
2
Iron, edge, sole and heel.
1
9
*
3.10.1.3 Type 1, size B.- In addition to requirements of 3.10.1 and
3.10.1.1, the machine with all attachments installed shall not exceed 11
feet in length. The attachments, unless otherwise specified (see 6.2),
shall be as tabulated in Table II and mounted either left to right or
right to left in the order listed, as specified (see 6.2).
TABLE II -
Type I, size B shoe finishing machine
Quantity
Item No.
Nomenclature
Required
1
Cutter, forepart.
1
2
Heel trimmer with shank sander and wire
brush attachment.
1
Grinder attachment.
1
3
4
1
Heel breaster.
Scouring wheel, flat surface, 1-3/8 inch
width by 5 inch diameter (with metal
protective edge when specified (see 6.2) ).
2
1
Brush, burnishing.
Bottom sander, 4 inch width.
1
Bottom leveler, 4 inch width.
1
Scouring wheel, flat surface, 1-3/8 inch
width by 5 inch diameter (with metal
protective edge, when specified (see 6.2) ).
7
